A Quieter & CO2 free Solution for Construction Sites
Power Your Site with Hydrogen Fuel Cells
PowerUP’s hydrogen fuel cell generator significantly reduces noise pollution on construction sites by operating much more quietly than traditional internal combustion generators.
Unlike internal combustion engines, which produce loud mechanical noise and exhaust sounds, hydrogen fuel cells generate electricity through a chemical reaction that emits only water vapor and minimal noise. This quieter operation not only creates a more pleasant working environment for construction workers but also minimizes disturbances to nearby residents and businesses, making it an ideal solution for urban construction projects.
Key values
Minimal maintenance
Silent & odorless
Zero CO2 emission
Enchanced safety
Plug & Play solution
NOx-Free Construction with Hydrogen Fuel Cells
PoC testing for 2 construction sites (3KW) of VolkerWessels Netherlands is successfully underway since Q2 2024, in partnership with a Dutch reseller. VolkerWessels, a leading construction company in the Netherlands, is using hydrogen fuel to achieve emission-free construction sites. This initiative is part of their broader strategy to reduce environmental impact and address the NOx crisis in the Netherlands.
UP400
First Step in
Energy
Independence
UP400 is a perfect starting point for off-grid power needs, and it allows full grid independence when connected to solar panels, wind turbines, or even your electrolyser.
| Nominal power output | 400 W |
| Nominal output voltage | 12/24 V |
| Current at 24 V | 34.7 A |
| Fuel | Compressed hydrogen (>99.97%) |
| Fuel consumption at max power | 5.2 normal l/min (26 g/hour) |
| Dimensions (L × W × H) | 700 × 222 × 312 mm |
| Weight | 21 kg |
| Operating ambient temperature | -5 °C to 40 °C |
| Noise level | 45 dB |
UP1K
Reliable Backup Power for Critical Needs
This 1kW generator is an ideal solution for disaster relief or powering tools in the construction or defence sector. Pair it with batteries, solar panels, or wind turbines for a smart microgrid.
| Nominal power output | 1000 W |
| Nominal output voltage | 12/24 V |
| Current at 24 V | 41.7 A |
| Fuel | Compressed hydrogen (>99.97%) |
| Fuel consumption at max power | 13 normal l/min (65 g/hour) |
| Dimensions (L × W × H) | 700 × 222 × 410 mm |
| Weight | 27 kg |
| Operating ambient temperature | -5 °C to 40 °C |
| Noise level | 45 dB |
UP3K
Revolutionising High-Demand Backup Power
The UP3K is a 3kW hydrogen fuel cell generator, perfectly suited for construction sites. Whether as a reliable backup power source for site offices, a primary generator for off-grid setups, or a station to charge tool batteries, the UP3K delivers dependable energy. Its modular design allows for scalable power, making it ideal for both standalone and hybrid applications, ensuring your operations run smoothly wherever you are.
- Grid drop detection
- 5x I/O connections (3x dry contact detection, 2x programmable relays)
- Remote monitoring and control
- Different working modes (Battery mode, Generator mode)
- Wide range of supported batteries
- (Optional) 19” Rack solutions (Indoor/outdoor)
- (Optional)Trailer-friendly mobile solution available (UPMobile)
|
Beginning of life (BOL): Continuous output power at 25°C Continuous output power at 40°C |
3000 W 2500 W |
|
After operation time >5000 h: Continuous output power at 25°C Continuous output power at 40°C |
2500 W 2000 W |
| System nominal voltage | 48 V DC |
| Fuel | Compressed hydrogen (>99.97%) |
| Fuel consumption | 0,065 kg/kWh at 0.5 bar(g) input pressure |
| Dimensions (L × W × H) | 589 x 304 x 578 mm |
| Weight | 42 kg |
| Communication / Protocols | CAN (optional: RS485, Bluetooth, USB) |
| Recommended temperature range | -5°C to +40°C (-30°C to +40°C with accessories) |
| Noise level | 65 dB |
UPSystem
Seamless Backup
with UP-Series Generators
In UPSystem, PowerUP generators are packaged in a rack with batteries, providing instant backup during blackouts, automatically switching on and off without manual input.
| UPSystem | 3K | 6K |
|---|---|---|
| Fuel cells | 1 cell | 2 cells |
| Power distribution | Customizable for 1-phase DC or AC or 3-phase AC | |
| System voltage | 48 V DC | |
| Output voltage | 48 V DC; 230 V AC; 400 V AC | |
| Output power | Constant 3 kW from fuel cell Peak loads 10 kW from battery |
Constant 6 kW from fuel cell Peak loads 20 kW from battery |
| Compatible H2 source | External cylinder or cylinder bank with pressure regulator to 0.5 bar g | |
| Battery bank option | Configurable: 48 V / min. 100 Ah (5 kWh) | 48 V / min. 200 Ah (10 kWh) |
| Dimensions (W, L, H) and weight |
600 × 800 × 1600 mm, 200 kg | 600 × 800 × 2000 mm, 250 kg |
| IP class | IP20 | |
| Features |
✓ Service monitoring ✓ IoT: Full system logs ✓ Remote monitoring and control ✓ Start/stop signal |
|
UPMobile
Reliable Hydrogen Power, Wherever You Go
UPMobile is available with either 3kW or 6kW of continuous fuel cell power. This versatile hydrogen fuel cell generator manages high peaks and continuity power needs of construction sites. The powerful UPMobile boasts an external hydrogen supply for enhanced flexibility and can be easily transported on a trailer.
- Screen
- Service monitoring
- IoT: Full system logs
- Remote monitoring and control
- Start/stop signal
| System voltage (VDC) | 42–75 VDC |
| Output voltage | 42–75 V DC; 230 V AC (1P); 400 V AC (3P) |
| Output current (A) | 0–300 A |
| Nominal power (kW) | 10 kW (BOL) – 9 kW (EOL) |
| Rated power (kW) | 15 kW (w/o battery) |
| FC peak power output (kW) | 16.4 kW |
| Battery extender capacity (kWh) | 6.8 kWh (1 module) |
| Battery extender peak power (kW) | 34 kW (12 min – 5C) |
| Cooling system | Deionized water (0.1 us/cm) |
| Fuel | Compressed hydrogen (>99.97%) |
| Fuel consumption per kWh | 60–73 g/kWh |
| Size (L × W × H) | 1900 × 1500 × 1500 mm |
| Weight (kg) | 220 kg |
| Start temperature (°C) | > -10°C |
| Operating temperature (°C) | from 5°C to 60°C |
| Operating hours (h) | 20 000 h |
| IP rating | IP54 |
| Noise level | 65 dB |
Hydrogen Safety & Consumption
PowerUP prioritizes safety with advanced hydrogen system for fuel cells
